Oxon-W1
Product advantage
All metal/mechanical interlock/coded key
Product characteristics
All-metal body, stainless steel components, head can be rotated in four directions, multi-angle installation.Locking force > 3000N.
3 way forced mechanical contact, safe and reliable.
Single opening mechanical code key, in line with LOTO specified technical requirements.
Highlight the large indicator window to clearly understand the lock status.
M12 Aviation connector, fast connection, water and dust resistant.
- Parameters
Product advantage
All metal/mechanical interlock/coded key
Product characteristics
All-metal body, stainless steel components, head can be rotated in four directions, multi-angle installation.Locking force > 3000N.
3 way forced mechanical contact, safe and reliable.
Single opening mechanical code key, in line with LOTO specified technical requirements.
Highlight the large indicator window to clearly understand the lock status.
M12 Aviation connector, fast connection, water and dust resistant.
Power | |
Power supply | 24V DC |
Voltage tolerance | +10% /-10% |
Voltage tolerance | 0.1W |
Outpu | |
Security output | 2NC |
Signal output | 1NO/1NC |
Contact capacity | |
Contact load | ＜2A（24VDC） |
General parameters | |
Shell material | Aluminum-carbide |
Operating unit | 304 stainless steel |
Dimensions | 198mm×40mm×40mm |
Safety standards | |
Standards | EN 60947-5-1 IEC 61326-3-1 EN ISO 13849-1 ISO 14119 |
Ordering information | |
Oxon-W1 | 01120401100 |
- Used for monitoring various security doors and Windows.
- Force security output:
- 2NC;
- 1NO/1NC signal contact.
Applicable industry:
- Automated production line
- Robot production line
- Hazardous test area
- Isolation site
